Laboratory Class II A2 Biosafety Cabinet
Features:
1. LCD Display control panel helps to monitor all the safety parameters for better user interface
2. Emission of 253.7 nanometers UV light for most efficient sterilization in cleanroom
3. The transparent side glass windows maximize light and visibility inside the cabinet, providing a bright and open working environment.
1. A2 Biosafety Cabinet Material
The A2 biosafety cabinet body is made of cold-rolled steel sheet, processed by laser cutting with error difference less than 0.1 mm, CNC folding, full wedding, arc welding, and more than 230-degree high-temperature epoxy coating. Worktop is designed according to the fluid dynamics by stainless steel
2.A2 Biosafety Cabinet Application
A2 biosafety cabinet offers three protection to lab technicians,, testing samples as well as lab environment. The airflow system is 30% air exhausted out AND 70% air is returned to the room. A Class II A2 biological safety cabinet is also called a full exhausting hood, which is very necessary when significant amounts of radionuclides and volatile chemicals are expected to be used in the laboratory testing.
3. A2 Biosafety Cabinet Specification
Model | BSC-4FA2(4′) | BSC-3FA2-GL(3′) BSC-3FA2-NA(3′) | BSC-4FA2-GL(4′) BSC-4FA2-NA(4′) | BSC-6FA2-GL(6′) BSC-6FA2-NA(6′) | |
External Size (W*D*H)mm | 1383*775*2295 | 1087*775*2265 | 1383*775*2295 | 1873*775*2295 | |
Internal Size (W*D*H)mm | 1210*600*660 | 910*600*660 | 1210*600*660 | 1700*600*660 | |
Work Surface Height | 750mm | ||||
Max Opening | 550mm (22’’) | 520mm(20.5’’) | 550mm (22’’) | 550mm (22’’) | |
Tested Opening | Safety height 200mm (8”) | Safety height 254mm (10’’) | Safety height 254mm (10’’) | Safety height 254mm (10’’) | |
Airflow Volume | Inflow | 462m3/h(272cfm) | 441m3/h(259cfm) | 587m3/h(346cfm) | 824m3/h(485cfm) |
Down flow | 65%:863m3/h(507cfm) | 60%:649m3/h(382cfm) | 60%:863m3/h(507cfm) | 60%:1212m3/h(713cfm) | |
Exhaust | 35%:462m3/h(272cfm) | 40%:441m3/h(259cfm) | 40%:587m3/h(346cfm) | 40%:824m3/h(485cfm) | |
Front Window | Motorized. Two-layer laminated toughened glass ≥5mm. Anti UV | ||||
ULPA Filter | Two, 99.9995% efficiency at 0.12μm, filter life indicator | ||||
Filter Guard Type | Aluminum alloy frame | ||||
Noise | NSF 49≤67 dB/EN 12469≤65 dB | ||||
Illumination | ≥1000Lux | ||||
Display | LCD Display | ||||
Waterproof Socket | 2, Total consumption:≤500W | ||||
Tap | Water tap*1, Gas tap *1 | ||||
Ground Resistance | ≤ 0.10Ω | ||||
Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz, Full load Amps: 9A, BTU/Hr: 1689 | ||||
Consumption | 400W | 300W | 400W | 500W | |
Alarm | Abnormal airflow velocity; Filter replacement; Front window at unsafe height. | ||||
DC Motor | One ECM motor, 110V& 220V acceptable, Speed adjustable, high efficiency and low power consumption | ||||
Material | Working area: 304stainless steel/ Frame and Decorative Plate: cold-rolled steel with anti-bacteria power coating | ||||
UV Lamp | 30W | 18W | 30W | 40W | |
Germicidal UV lamp, Emission of 253.7 nanometers for most efficient decontamination | |||||
Illuminating Lamp | 18W*2 | 10W*2 | 18W*2 | 22W*2 | |
LED lamp | |||||
Standard Accessory | Illuminating lamp, UV lamp *2, Base stand, SS water & gas taps, Drain valve, Waterproof sockets, Stainless Steel I.V. Bar with 10 hooks | ||||
Optional Accessory | Armrest, Airflow tester, Formalin fumigation sterilizer, Infrared sterilizer, Electric height adjustable base stand, Remote control | ||||
Package Size (W*D*H)mm | 1540*1080*1900 | 1250*1080*1840 | 1540*1080*1900 | 2020*1080*1900 | |
Gross Weight(kg) | 334 | 270 | 340 | 370 | |
